Stainless steel liquidation can-PYG series stainless steel liquidation cans strictly follow \"Pharmaceutical Production Quality Management Specification\" GMP General (1998 Revised Edition) Article 31, 32 Requirements, Stainless Steel Fluid Tank According to GB150-98 \"Steel The pressure vessel \", JB / T4735-97\" Steel welding normal pressure container \"requires design and manufacturing test.
◆ Stainless steel tank container insulation materials use high temperature resistance, anti-aging polyamide foam or pearl cotton.
◆ Stainless steel liquid tank interface adopts international general standard ISO quick-discharge card, liner ,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
Cold rolling raw matt, in line with GMP medical standards.
◆ The seal of the stirrer is used in an inlet hygiene-level mechanical stirring seal or magnetic full sealing stirring apparatus, and the stirring speed can be optionally optionally.
◆ The tube is provided with a liquid level count (static pressure, capacitive, unconflexible, ultrasonic, glass tube), air respirator, thermometer (digital explicit or dial), CIP cleaning port, view mirror , Explosion-proof light (visual view lamp integration), SIP sterilization, into and out of liquid port and hygiene, etc.
◆ Volume 100L-10000L and other specifications can also be designed, manufactured according to customer needs.
◆ Stainless steel liquidation tank randomly accompanied GMP verification data (including material report, foreign purchase certificate, verification form, etc.)
Other tank series outside of stainless steel liquid tank: alcohol precipitate tank, reactor, seepage tank, crystalline tank, seed can, fermenter (seed can), horizontal insulation storage tank, storage tank, distilled water storage tank
| Nominal volume | Working pressure (MPa) | Work temperature (° C) | Stir speed (rotation / min) | H (mm) | H1 (mm) | D (mm) | D1 (mm) | H (mm) |
| 100 | 0.25 | 100 | 0-720 | 1750 | 450 | 750 | 550 | 300 |
| 200 | 0.25 | 100 | 0-720 | 1950 | 600 | 850 | 650 | 300 |
| 600 | 0.25 | 100 | 0-720 | 2500 | 1000 | 1100 | 900 | 350 |
| 1000 | 0.25 | 100 | 0-720 | 2850 | 1200 | 1300 | 1100 | 350 |
| 2000 | 0.25 | 100 | 0-720 | 3350 | 1500 | 1500 | 1300 | 350 |
| 3000 | 0.25 | 100 | 0-720 | 3700 | 1700 | 1700 | 1500 | 350 |
| 5000 | 0.25 | 100 | 0-720 | 4250 | 2000 | 2000 | 1800 | 400 |
| 10000 | 0.25 | 100 | 0-720 | 5000 | 2500 | 2500 | 2300 | 400 |
Stainless steel liquidation can-PYG series stainless steel liquidation cans strictly follow \"Pharmaceutical Production Quality Management Specification\" GMP General (1998 Revised Edition) Article 31, 32 Requirements, Stainless Steel Fluid Tank According to GB150-98 \"Steel The pressure vessel \", JB / T4735-97\" Steel welding normal pressure container \"requires design and manufacturing test.
◆ Stainless steel tank container insulation materials use high temperature resistance, anti-aging polyamide foam or pearl cotton.
◆ Stainless steel liquid tank interface adopts international general standard ISO quick-discharge card, liner ,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
Cold rolling raw matt, in line with GMP medical standards.
◆ The seal of the stirrer is used in an inlet hygiene-level mechanical stirring seal or magnetic full sealing stirring apparatus, and the stirring speed can be optionally optionally.
◆ The tube is provided with a liquid level count (static pressure, capacitive, unconflexible, ultrasonic, glass tube), air respirator, thermometer (digital explicit or dial), CIP cleaning port, view mirror , Explosion-proof light (visual view lamp integration), SIP sterilization, into and out of liquid port and hygiene, etc.
◆ Volume 100L-10000L and other specifications can also be designed, manufactured according to customer needs.
◆ Stainless steel liquidation tank randomly accompanied GMP verification data (including material report, foreign purchase certificate, verification form, etc.)
Other tank series outside of stainless steel liquid tank: alcohol precipitate tank, reactor, seepage tank, crystalline tank, seed can, fermenter (seed can), horizontal insulation storage tank, storage tank, distilled water storage tank
| Nominal volume | Working pressure (MPa) | Work temperature (° C) | Stir speed (rotation / min) | H (mm) | H1 (mm) | D (mm) | D1 (mm) | H (mm) |
| 100 | 0.25 | 100 | 0-720 | 1750 | 450 | 750 | 550 | 300 |
| 200 | 0.25 | 100 | 0-720 | 1950 | 600 | 850 | 650 | 300 |
| 600 | 0.25 | 100 | 0-720 | 2500 | 1000 | 1100 | 900 | 350 |
| 1000 | 0.25 | 100 | 0-720 | 2850 | 1200 | 1300 | 1100 | 350 |
| 2000 | 0.25 | 100 | 0-720 | 3350 | 1500 | 1500 | 1300 | 350 |
| 3000 | 0.25 | 100 | 0-720 | 3700 | 1700 | 1700 | 1500 | 350 |
| 5000 | 0.25 | 100 | 0-720 | 4250 | 2000 | 2000 | 1800 | 400 |
| 10000 | 0.25 | 100 | 0-720 | 5000 | 2500 | 2500 | 2300 | 400 |
